10A DC-DC SSR

10A DC-DC SSR
$9.50

Availability: In stock

It's for switching DC power source from 5V to 220V. The control signal is 3-32V DC. Maximum AC current 10A. Please note it needs a heatsink to work with it if the current is higher than 7A.
Description

Details

Manufacture Mager
Manufacture’s Part Number SSR-10 DD (MGR-1DD200D10)
Triggering Voltage 3-32VDC
Output Voltage 5-220VDC
Current Rating 10A
On Voltage ≤2.3V
Off Leakage Current ≤2mA
On-off Time ≤10mS
Dielectric Strength 2000VAC
Insulation Resistance 500MΩ/500VDC
Ambient Temperature -30~+75 ℃
Dimensions 2.25x1.75x1.25
Weight 90g
Approval CE


Note: To test an SSR, the easiest way is to use a bulb. Please check the following video. A multimeter won't help since there's a small current leakage even if the output of the SSR is open.

Youtube video link.
